ROOFTOP SOLAR MOUNTING STRUCTURE FOR COMMERCIAL BUILDINGS
A robust mounting system for shopping centers, offices and warehouses. The structure is engineered for high winds and heavy snow, customized to the roof type and panel layout, and fabricated by extruding, forming, cutting, punching and welding in our factory. Materials include anodized aluminum, hot-dip galvanized steel, ZAM steel and stainless steel.
Key advantages
Key advantages
- Light weight, high strength, corrosion resistant
- Customized to your roof and layout
- Fast installation with pre-cut parts
- All fasteners included
Specifications
| Materials | Anodized aluminum, HDG steel, ZAM, stainless steel |
|---|---|
| Processes | Extruding, forming, cutting, punching, welding |
| Tilt | 5°–30°, adjustable |
| Roof types | Metal sheet, concrete, membrane |
| Fasteners | Complete set supplied |
| Warranty | 10 years |
RELATED PRODUCTS
More from Solar Steel Structures.
-
Solar Carport Steel Structure
Cantilever or double-column PV carport for parking lots. Shades cars and generates power at the same time.
-
Industrial Solar Mounting Structure
PV mounting for factory roofs and plants: SUS 304 / aluminum 6005-T5, 60 m/s wind, 25-year life.
-
BIPV Steel Roof Structure
Building-integrated PV roof on an H-beam frame: the panels are the roof. For showrooms, malls and offices.
-
Solar Pergola & Canopy Structure
BIPV pergola and canopy brackets for homes and courtyards, ZAM coated, with all screws and rail nuts included.
FREQUENTLY ASKED QUESTIONS
STEEL OR ALUMINUM MOUNTING?
Galvanized or ZAM steel is stronger and more economical for carports and large spans; aluminum is lighter for rooftops. We supply both and often combine them.
WHICH PANELS DO YOUR STRUCTURES FIT?
Our rails and clamps fit most standard framed PV modules. Tell us the module size and quantity and we will size the structure.
WHAT DO YOU NEED FOR A QUOTE?
Dimensions (length, width, height or number of floors), the site location for wind, snow and seismic loads, the intended use, and your preferred roof and wall materials. A sketch or a photo of a similar building is enough to start.
CAN AN EXISTING ROOF CARRY SOLAR PANELS?
Often yes, but it must be checked. Send us the roof drawings or photos and we will check the extra load and recommend reinforcement if needed.
HOW IS IT PACKED AND SHIPPED?
Members are numbered, bundled and loaded in 40 ft containers or on flat racks with a packing list and erection drawings. We ship FOB Ningbo or Shanghai, or CIF to your port.
WHAT IS THE LEAD TIME?
Most orders ship 35–55 days after drawing approval, depending on tonnage and coating. Urgent projects can be split into phased shipments.
