FREE LAYOUT DESIGN
Send your building size and location. We reply with a layout drawing and a priced material list, usually within 48 hours.
RED STEEL STRUCTURE WORKSHOP WITH WELDED H COLUMNS
This workshop was built for a medical instruments manufacturer: 3,000 m² of production space on welded H columns and hot-rolled H beams, with red color steel sheet on the roof and walls. The frame was designed so the owner can add a floor or extend the building later without rebuilding the original structure.
Key advantages
Key advantages
- Expandable frame: extra floors or bays can be added later
- Large column-free production area
- Short build time compared with concrete
- Bright color cladding, a strong brand look for your plant
Specifications
| Project | Medical instruments workshop |
|---|---|
| Floor area | 3,000 m² |
| Main structure | Welded H columns, hot-rolled H beams |
| Welding | Automatic submerged-arc welding |
| Connection | High-strength bolts |
| Roof | Red color steel sheet |
| Wall | Red color steel sheet |
| Packing | Bundled steel members |
| Lead time | About 36 days |
RELATED PRODUCTS
More from Warehouses & Workshops.
-
Insulated Steel Structure Workshop
3,500 m² welded H-beam workshop with insulated wall panels: color steel, insulation foam and aluminum foil.
-
Machinery Workshop with Crane Beams
Heavy steel truss workshop with overhead crane runway, multi-floor option and ISO 9001 fabrication.
-
Hot-Dip Galvanized Steel Warehouse
3,040 m² H-section warehouse frame, hot-dip galvanized for humid and coastal sites. Bolted for fast erection.
-
Bolted Steel Structure Warehouse
Prefabricated warehouse with anti-rust painted frame and bolted connections. Waterproof, fire-rated, wind and snow resistant.
FREQUENTLY ASKED QUESTIONS
HOW MUCH DOES A STEEL WAREHOUSE COST?
Price depends on span, height, loads, cladding and quantity. Most single-storey warehouses fall in a range we can quote quickly once we know size and location. Send the dimensions and site and we will return a priced material list, usually within 48 hours.
WHAT DO I NEED TO SEND FOR A QUOTE?
Length, width, eave height, location (for wind and snow loads), roof and wall material, and whether you need a crane, mezzanine, doors or windows. A sketch or a photo of a similar building also helps.
CAN YOU DESIGN TO LOCAL STANDARDS?
Yes. We work to Chinese GB codes by default and can check designs against the loads and standards your engineer specifies.
HOW IS THE BUILDING SHIPPED?
Members are numbered, bundled and loaded in 40 ft containers or flat racks with packing lists and erection drawings. We ship FOB Ningbo or Shanghai, or CIF to your port.
DO YOU INSTALL OVERSEAS?
We provide full erection drawings and can send engineers to guide your local team on site. Installation terms are agreed per project.
HOW LONG DOES A STEEL BUILDING LAST?
With proper coating and maintenance, a steel structure building has a design life of 50 years. Hot-dip galvanizing extends protection in coastal or humid sites.
